Dunli Condenser Fan Motor & Assembly - Aftermarket Replacement Addison Part No. 0515P-0783 - 550mm/230V-460V
$1,190.00
Skip to product information
Dunli Condenser Fan Motor & Assembly - Aftermarket Replacement Addison Part No. 0515P-0783 - 550mm/230V-460V
$1,190.00
Pickup available at 13263 SW 124th ST
Usually ready in 1 hour
| Unit | Axial Fan Motor with Fan Assembly | Noise | 72 - 73 dBA |
| Brand | Dunli | Rotation | CW, Looking into the End-Shield |
| Motor | Three-Phase Motor | Insulation Class | F |
| Model | YWF.A4T-550S-5FIIIV04 | Motor Protection | Overheated Protection Function, Cut Off Temperature 150 - 160 °C |
| Voltage | 230 V - 460 V | Protection Class | IP54 |
| Frequency | 60 Hz | Ambient Temperature |
-30°C + 60°C |
| Input Power | 650 - 750 W | Bearings |
Ball Bearings |
| Current | 2.1 - 1.2 A | Mounting Type | Horizontal or Vertical |
| Speed | 1460 - 1540 r/min | Net Weight/ Gross Weight | 24.69/29.32 lbs |
| Air Flow | 9100 - 9450 m³/h | Package Size | 23.62 x 23.62 x 8.66 in |
